Cheap Good Cylinder Heads

jelco · Nov 18, 2020

Where do you find good and cheap cylinder heads?
A set of these for $280 + valves + springs, reuse old rocker arms = $400
https://www.ebay.com/itm/393005918509
https://www.ebay.com/itm/322892146731

sellecting cylinder heads

you might want to watch this, its comparing the vortec SBC heads vs a CNC aluminum 210cc SBC head on a 383 (yes a head that large actually works and has a great deal more low and mid rpm torque that you may have been lead to believe, with 210cc ports and yes there are better heads in the...

garage.grumpysperformance.com

Buy used, cleaned Vortec heads with old valves and springs + Vortec intake manifold = $570?

*Currently I have this*
Engine Name: 350 LM1, #10066036
Horsepower: 249 HP @ 5,000 RPM
Torque: 304 Ft/Lbs @ 3,500 RPM
Compression Ratio: 8.50 to 1
Block: 4 – Bolt, 2 Piece Rear Seal, 4.000” Bore
Crankshaft: Cast Nodular 3.480” Stroke
Heads: Cast Iron, 76cc
Valves: 1.940” / 1.500”
Camshaft lift: 0.390” / 0.410” Hydraulic
Duration @ 0.050”: 195° / 202°
Intake: Not Included

I probably have this stock cam:
Hydraulic Flat tappet Camshaft- #14088839
Intake Lift-.383" Exhaust Lift-.401"
Intake Duration @ .050"- 194 Exhaust Duration @.050"- 202
Lobe Seperation-112

Carburetor: edelbrock 1406
Intake manifold: Edelbrock 2601

Headers: currently just have exhaust manifolds

The goal is to have a little bit of power on a budget for a daily driver.

valve seat angles and air flow

USE THE CALCULATORS http://www.rbracing-rsr.com/runnertorquecalc.html http://www.wallaceracing.com/chokepoint.php http://www.wallaceracing.com/header_length.php http://www.wallaceracing.com/chokepoint.php http://www.rbracing-rsr.com/runnertorquecalc.html...

garage.grumpysperformance.com

watch this video

Grumpy · Nov 18, 2020

Grumpy · Nov 18, 2020

if you skip over reading the links and sub-links,
you're surely missingthe VAST majority,
of the related info you'll need
http://www.hotrod.com/articles/ccrp-1209-eight-budget-sbc-head-shootout/

https://www.motortrend.com/how-to/ccrp-1209-eight-budget-sbc-head-shootout/

http://www.superchevy.com/how-to/engines-drivetrain/sucp-0705-budget-chevy-cylinder-heads/

OMG I cracked my head!!!

I CAN NOT BELIEVE A MAJOR, world renown company like automotive company named ARP would make such a piece of crap stud like the one that just cracked my cylinder head… WHAT were they thinking?? How many cylinder heads have the stupid insane studs have been cracked by these. And the package...

garage.grumpysperformance.com

hey I just picked up FUELIE HEADS FOR CHEAP..

"hey GRUMPYVETTE,I just picked up 492 FUELIE HEADS FOR CHEAP..CAN I GET THEM TO PRODUCE 400 HP!" SURE you can get those heads to produce 400hp, but for the same money you could most likely make an additional 40-60 more hp with better aftermarket cylinder heads,TECHNOLOGY HAS ADVANCED A GREAT...

garage.grumpysperformance.com

http://www.superchevy.com/how-to/engines-drivetrain/sucp-0803-performance-cylinder-head-comparison/

https://www.chevydiy.com/ultimate-chevy-big-inch-small-block-cylinder-heads-cheat-sheet/

https://www.chevydiy.com/the-complete-cylinder-head-guide-for-chevy-small-block-engines/

port speeds and area

I CAN,T EVEN TELL YOU HOW INSANE SOME CONVERSATIONS I HAVE SEEN GUYS GET EVOLVED IN ARE! GUYS TELL YOU A 210CC air flow research HEADS GOING TO ABSOLUTELY KILL Torque ON A 383 BUT ITS FINE FOR A 400 SBC, WHAT TOTAL b.s, your cylinder heads port size needs to be selected with both displacement...

garage.grumpysperformance.com

https://www.hemmings.com/stories/article/performance-aftermarket-chevy-small-block-cylinder-heads

http://garage.grumpysperformance.co...ed-up-fuelie-heads-for-cheap.2099/#post-85190

http://garage.grumpysperformance.co...d-to-head-test-stock-vs-dart.5364/#post-16066

https://www.enginebuildermag.com/20...ars-cylinder-heads-key-unlocking-performance/

yeah everything thats even decent quality is expensive but shop carefully

https://www.summitracing.com/parts/bro-1021004

https://www.jegs.com/i/ProMaxx-Performance/723/2181/10002/-1

https://www.jegs.com/p/ProMaxx-Perf...hevy-Aluminum-Cylinder-Heads/2786544/10002/-1

YouTube

Enjoy the videos and music you love, upload original content, and share it all with friends, family, and the world on YouTube.

www.youtube.com

jelco · Nov 19, 2020

Yes, I would make sure to get the correct valves. I was asking for opinions on the type of heads to get based on the camshaft and engine I have.
Information overload but looks like lots of good links. Thanks!

Grumpy · Nov 19, 2020

you've got dozens of options, but I generally use the brodix IK 180 cc heads on similar builds,
or the brodix 200 cc port heads on more aggressive builds,used mostly on street driven cars
simply because they are high quality at a reasonable price,
and you see few issues, something thats much less true in some less expensive heads,
and it really sucks to spend $600-$700 on the cheaper heads and find out you have
valve train clearance, component alignment, the wrong valve spring load rates,
port flow restrictions, valve sealing, rocker arm algnment, push rod to guide clearance .
,valve seals that don,t fit correctly, spring bind and similar issues

https://www.summitracing.com/parts/bro-1021004

related threads
http://garage.grumpysperformance.co...train-clearances-and-problems.528/#post-79625

http://garage.grumpysperformance.co...tched-valve-spring-required.13774/#post-77425

OMG I cracked my head!!!

I CAN NOT BELIEVE A MAJOR, world renown company like automotive company named ARP would make such a piece of crap stud like the one that just cracked my cylinder head… WHAT were they thinking?? How many cylinder heads have the stupid insane studs have been cracked by these. And the package...

garage.grumpysperformance.com

http://garage.grumpysperformance.co...rect-custom-length-pushrods.14241/#post-72353

http://garage.grumpysperformance.com/index.php?threads/stock-gm-push-rod-length.3844/#post-70588

http://garage.grumpysperformance.com/index.php?threads/rocker-push-rod-wear-issues.9815/#post-56169

http://garage.grumpysperformance.co...-rockers-and-the-pushrods-rub.198/#post-46839

http://garage.grumpysperformance.co...ting-up-the-valve-train.181/page-2#post-43988

http://garage.grumpysperformance.com/index.php?threads/removing-valve-seals.4283/#post-98512

Grumpy · Feb 7, 2023

https://garage.grumpysperformance.c...t-angles-and-air-flow.8460/page-2#post-110196

Grumpy · Jul 18, 2023

for an off brand head these promax 215cc SBC heads,
provide a decent value once cleaned up and a decent valve jobs been done
(ideally a multi angle valve job and use steel cup valve spring seats , to protect the aluminum heads,
and light weight retainers and maybe beehive valve springs)(smaller diam. retainers weigh less and beehive valve springs less prone to harmonic valve spring surge issues) and (a rocker stud girdle might help also)
as usual talk too both the cam and head manufacturers and your machine shop, or cylinder head shop guy you trust

obviously you'll need the correct valve springs and a decent hydraulic roller cam,
with between about 230-240 duration and about a .550-610 lift (use 1.6:1 ratio roller rockers)
that in turn will require a manual transmission or a 3200 rpm stall converter and about a 3.54:1-4.11:1 rear gear,
and about a 383-406 cid and about 10:1-11:1 compression ratio, in most cars to max power
