460 ford potential related engine build links

[Grumpy]

I don,t know if its a local deal or its nation wide but finding a 427-454 Chevy big block always seems to be Much more difficult than the more common, 460 ford engines.
the ford 385 series 460 engine has a wider bore spacing and potential has a few advantages over a mild chevy big block, especially if your willing to invest in decent after market aluminum heads, since most stock 460 cylinder heads are less than ideal, like the peanut port BBC heads
the most common problem with the BBF is the stock cylinder heads in many OEM engines.
theres no doubt the availability of much better quality components becoming available in the last 6-8 years has helped the 385 series ford big block engines power potential.

SKIPPING THE LINKS AND SUB-LINKS WOULD BE A MISTAKE
http://www.mustangandfords.com/how-to/engine/mdmp-1212-colossal-kaase-combo-460-big-block/

https://www.enginebuildermag.com/2015/09/ford-boss-429-versus-todays-fr-9/

http://garage.grumpysperformance.com/index.php?threads/afr-new-bbf-460-heads.10911/#post-56665

https://www.summitracing.com/parts/tfs-5341t010-c01/media/chartsandguides

http://garage.grumpysperformance.com/index.php?threads/sources-for-ford-blocks.4695/#post-12729

https://www.summitracing.com/parts/tfs-5451t804-c04/media/chartsandguides

http://www.hotrod.com/articles/big-block-engines/

http://home.earthlink.net/~kaneofthenation/highflowdynamics/id15.html

http://garage.grumpysperformance.com/index.php?threads/sources-for-ford-blocks.4695/#post-49644

http://garage.grumpysperformance.co...good-ideas-that-got-canceled.1107/#post-46786

http://www.hotrod.com/articles/ccrp-1006-installing-557-demon-stroker-kit/

http://www.hotrod.com/articles/0906phr-big-block-ford-engine/

http://www.enginebuildermag.com/2016/08/building-a-ford-460-stroker/

http://www.speedwaymotors.com/429-460-Ford-Stroker-Kit,5530.html

http://www.coasthigh.com/Ford-460-based-engine-kits-s/1301.htm

https://www.powerblocktv.com/episode/HP2009-23/battle-of-the-big-blocks#.WKnyo_nyvcc

watch this link



[Grumpy]

BBF Head Heirarchy from best to worst

1. C&C C-441 Hemi
2. C&C B-441 Hemi
3. HFD Pentroof Hemi
4. C&C A-441 Hemi
5. Ford Motorsport A-441 Hemi (No longer in production)
6. Indy Cylinder Hemi
7. Ford E-460 Pro Stock
8. Blue Thunder Thor Gen II
9. Blue Thunder Thor Gen I
10. Profiler C-Replacement
11. Ford C-460
12. Ford D-460 Pro Stock (No longer in production)
13. Ford Motorsport bastard Pro Stock (There are various stages) (No longer in production)
14. IDT Eliminator A-460
15. EX514
16. New TFS A-460 18-bolt
18. New TFS A-460
19. EX514 Cast Iron A-460
20. IDT Eliminator Cast Iron A-460
21. Older TFS A-460 (No longer in production)
22. Ford Motorsport A-460 (No longer in production)
23. Ford Motorsport A-460 (Ford exhaust port) (No longer in production)
24. Kaase Hemi
25. Boss 429 Replacement
26. Ford Stock Hemi (No longer in production)
27. TFS B-460 (small port) (No longer in production)
28. Ford Motorsport B-460 (small port) (No longer in production)
29. Kaase P-51
30. Ford Racing Parts SCJ
31. Blue Thunder CJ with Chevy exhaust flange
32. Blue Thunder CJ with raised Ford exhaust port
33. TFS Street
34. Blue Thunder CJ with stock Ford exhaust port location
35. TFS CJ (No longer in production)
36. Ford A-429 CJ (No longer in production)
37. Edelbrock CJ
38. Ford Cast Iron DOOE-R CJ (No longer in production)
39. Edelbrock 75cc Standard Port
40. Ford Cast iron PI (No longer in production)
41. ProComp Aluminum 74cc
42. Ford Cast Iron C8VE (No longer in production)
43. Ford Cast Iron C9VE (No longer in production)
44. Ford Cast Iron DOVE (No longer in production)
45. Edelbrock 95cc Standard Port
46. ProComp Aluminum 95cc
47. Ford Cast iron D3VE (No longer in production)
48. Ford Cast Iron E6TE (No longer in production)
49. Ford Cast Iron F8TE (No longer in production)
50. Ford Cast Iron "Fuelie" F3TE (No longer in production)
51. Ford Cast Iron "Fuelie" E7TE (No longer in production)
52. Ford Cast iron D2VE (No longer in production)
53. Ford Cast Iron D8TE (or E9TE, to be confirmed) (No longer in production)



[Grumpy]



[Grumpy]

AFR - Airflow Research 3838: 300cc Bullitt Series Cylinder Heads 300cc Intake Ports - JEGS High Performance

Buy AFR - Airflow Research 3838 at JEGS: AFR - Airflow Research 300cc Bullitt Series Cylinder Heads 300cc Intake Ports. Guaranteed lowest price!

www.jegs.com

Bullitt CNC

Shop Bullitt CNC Parts

www.airflowresearch.com



[Grumpy]

A 598 cubic inch Big Block Ford is a high-performance stroker engine, typically based on the Ford 385-series (460) or aftermarket A460 block, producing over 800–1,000+ horsepower. Utilizing a 4.600-inch bore and 4.5-inch stroke, these engines are popular for drag racing, boat racing, and high-performance street trucks, often featuring aluminum heads and forged rotating assemblies.
YouTube +5
Key Engine Components & Specs

• Block: Usually an aftermarket Ford Racing A460 or similar aluminum/iron block for strength.
• Rotating Assembly: Typically features a 4.5-inch stroke forged crankshaft (e.g., Callies or SCAT) and 6.535-inch H-beam rods.
• Heads: High-flow aluminum heads, such as Trick Flow PowerPort A460, are standard, often flowing over 450 CFM.
• Compression: Ratios often range from 10:1 (pump gas) to over 14:1 (race fuel).
• Performance: Naturally aspirated builds frequently produce over 1,000 HP at 7,000 RPM, with torque exceeding 850 lb-ft.
  YouTube +5

Common Applications

• Drag Racing/Pulling: Built by specialized shops like CNC-Motorsports for maximum power.
• Street/Strip: High-horsepower street car builds (e.g., hot rod trucks).
  YouTube +2

Example Builds

• CNC-Motorsports 598: 800+ HP pump gas crate engine.
• Hot Rod Network 598: Mechanically injected, supercharged 1,194 HP build.
• Engine Builder 598: 1,030 HP race engine.



[Grumpy]

Jon Kaase Racing Boss 9 cylinder heads are designed to fit big-block Fords while retaining stock port locations, boasting impressive flow rates, with intake ports peaking around 407 CFM and exhaust ports at 310 CFM at 0.600-inch lift. These heads, often featuring 2.300-inch intake valves, are known for strong performance in high-horsepower applications.

Jon Kaase Racing Engines +2
Key Flow Numbers (Approximate, per Kaase Racing):

• Intake: Peaks at approximately


  at


  lift.
• Exhaust: Peaks at approximately


  at


  lift.
• Mid-Lift: Shows high flow even at lower lifts (e.g.,

  at

  lift).
• Efficiency: The design offers a strong exhaust-to-intake (E/I) percentage of roughly 70%.


  Jon Kaase Racing Engines +1

These heads are frequently used on large-displacement engines, such as the 598 cubic inch Boss 9, which can produce over 1,000 horsepower.

Ford Big Block 572-598 Short Blocks - Engines | CNC Motorsports

Best performance 572-598 big cubic inch ford short blocks are here! Fully machined & blue-printed. Guaranteed quality, custom builds available

cnc-motorsports.com



[Grumpy]

Shafiroff Chevy, Ford and LS Supercharged Long Blocks

Shafiroff Chevy, Ford and LS Supercharged Long Blocks

www.shafiroff.com



[Grumpy]

Jon Kaase Racing Boss 9 cylinder heads are designed to fit big-block Fords while retaining stock port locations, boasting impressive flow rates, with intake ports peaking around 407 CFM and exhaust ports at 310 CFM at 0.600-inch lift. These heads, often featuring 2.300-inch intake valves, are known for strong performance in high-horsepower applications.

Jon Kaase Racing Engines +2
Key Flow Numbers (Approximate, per Kaase Racing):

• Intake: Peaks at approximately


  at


  lift.
• Exhaust: Peaks at approximately


  at


  lift.
• Mid-Lift: Shows high flow even at lower lifts (e.g.,


  at


  lift).
• Efficiency: The design offers a strong exhaust-to-intake (E/I) percentage of roughly 70%.


  Jon Kaase Racing Engines +1

These heads are frequently used on large-displacement engines, such as the 598 cubic inch Boss 9, which can produce over 1,000 horsepower.



[Grumpy]

Kaase Boss Nine Cylinder Heads

Despite the racing successes of the original Boss 429 Mustang the semi-hemi cylinder heads were weak. The combustion chambers cracked and their thin decks leaked around the O-ring head gaskets. Als…

jonkaaseracingengines.com

Kaase Boss Nine Valve Covers

For us, the single finest identifying feature of the Boss 429 Ford is the valve cover. It has a unique appearance, and distinguishes this engine from all others. For that reason, we tried to make o…

jonkaaseracingengines.com



[Grumpy]
